SM3.0X Loupes

SM series medical loupes possesses all the features of the C series medical loupes, with smart design and fine view image, furthermore ,quite smaller lenses and ultra-light weight are the unique characteristic of the SM series loupes, which make it convenient and simple for the users.
  • SM3.0X

  • Ymarda

Availability:
Quantity:

Product Description

Brand Name

Ymarda

Model Number

SM300

magnification

3.0X

frame

TP frame, BP frame,Titanium frame,Metal frame

weight

30g

working distance

280-600mm

viewing angle

adjustable

field of view

90-110mm

material

optical lens

certificate

ISO9001:2008,CE


Optional frames:


Frames

Colors

Titanium frame

black , silver

Metal frame

black , silver,wine-red, purple(only for lady)

Half metal frameblack, silver

TP frame

pink, gold, silver, red, white, brown, black, blue

BP frame

gold, white, green, black, silver, red, blue




Optional working distance:

Item

Optical System

Working distance

Field of  View

Viewing Angle

Weight without  the frame)

3.0X-S

Compound Optics

280 - 380 mm

90mm

Adjustable

30g

3.0X-R

Compound Optics

360 - 460 mm

100mm

Adjustable

30g

3.0X-L

Compound Optics

440 - 540 mm

100mm

Adjustable

30g

3.0X-XL

Compound Optics

500 - 600 mm

110mm

Adjustable

30g


Others:

Warranty: One year

Supply ability :3000 pieces per month



Each loupe including the following :

Cloth case x1, cleaning cloth x1, head strap  x1, grip flip x1,  screw driver  x1,  lens cover x2

Previous:
Next:
Our factory specially produce all kinds of binocular medical loupes, we have flip-up loupes, clip-on loupes, headband loupes and TTL loupes, we also produce the loupes with the LED headlight.
